<3 jenjhq 1 100% Germany Origin
Z -Laser Vietnam – Z -Laser Viet Nam – Z -Laser-Vietnam

Item : 722135003

Z-LASER Z5-X20-H-F-640-elp45

SYSTEM SPECIFICATIONS:

Wavelength 640nm

Wavelength tolerance ±10nm

Wavelength drift (typ.) 0,25nm/K

Output power 5mW

Spatial mode Single Transverse Mode

RMS noise (20 Hz up to 20 MHz, typ.) <0,5%

Peak-to-Peak noise (20 Hz up to 20 MHz,

<1%,

typ.)

Boresight Error (typ.) typ. 3mrad

Pointing Stability <10µrad / K

Stability of output power ±3 % over the entire temperature range

Start-up time <2sec

Operating mode APC

Laser class (EN 60825-1) 1M

ELECTRICAL SPECIFICATIONS:

Supply Voltage 5-30VDC

Operating current (max.) <500mA

Electrical Isolation Potential-free housing

Connection I M12 5-Pin: A-Coding Male Connector

Power consumption <2.5W

Optional Interface I²C, RS-232 (5V)

OPTICAL SPECIFICATIONS:

Projection Line, homogenous intensity distribution

Optical configuration Extended DoF (elp)

Fan angle 45°

Line straightness <0,05%

Line orientation Parallel to indentation in the clamping area

Focus range focusable from 100mm to 10.000mm

Maximum frequency up to 400kHz

Rise time <100ns

Fall time <100ns

Signal level < +0,9V (VIL_max) & > +2,2V (VIH_min)

max. Input Voltage Vin 27VDC

Maximum bandwidth <10Hz

Linearity <5% (from 10% to 100% of laser power)

Active range 0-2VDC

Impedance 100 kΩ to internal VCC (3.3 V)

max. Input Voltage Vin 27VDC

ENVIRONMENTAL CONDITIONS:

Working Temperature -10°C to +50°C / 14°F to +122°F

Storage temperature -40°C to +85°C / -40°F to +185°F

Humidity < 90%, non-condensing

Dissipated heat (max.) <1W

Shock and vibration Acc. IEC EN 61373:2011, Cat. 2

MECHANICAL SPECIFICATIONS:

Weight (net) 125g / 0.28 lbs

Dimensions (ø x L) 20h7 x 117mm / 0.79 x 4.61 in

Material Stainless steel

Protection class IP67

2 100% Germany Origin

Z -Laser Vietnam

100910590

Z-LASER Z5M18B-F-640-lp45-sf

SYSTEM SPECIFICATIONS:

Wavelength 640nm

Wavelength tolerance ±10nm

Wavelength drift (typ.) 0,25nm/K

Output power 5mW

Boresight Error (typ.) <10mrad

Pointing Stability <15μrad / K

Stability of output power ±3 % over the entire temperature range

Operating mode APC

Laser class (EN 60825-1) 1M

ELECTRICAL SPECIFICATIONS:

Supply Voltage 5-30VDC

Operating current (max.) <400mA

Electrical Isolation Potential-free housing

Connection I M12x1 plug, 4pole

Power consumption <2,0W

OPTICAL SPECIFICATIONS:

Projection Line, homogenous intensity distribution

Optic lp45

Fan angle 45°

Line straightness <0,05%

Focus range focusable from 100mm to 10.000mm

DIGITAL MODULATION: –

ANALOGUE MODULATION: –

ENVIRONMENTAL CONDITIONS:

Working Temperature -10°C to +50°C / 14°F to +122°F

Storage temperature -40°C to +85°C / -40°F to +185°F

Humidity < 90%, non-condensing

Dissipated heat (max.) <1W

MECHANICAL SPECIFICATIONS:

Weight (net) 85 g / 0.19 lbs

Diameter 20mm

Length 108mm

Protection class IP67

1 100% EU Origin

AT2E Vietnam

Model: AT2E- PL-P KEG (450×450 mm )

Polarization Light for PET Preform: Stress Viewer

Tuychon

1.1 100% EU Origin

AT2E Vietnam

PET Defect catalog

1 100% EU Origin

AT2E Vietnam

Code: AT2E- PL-P KEG (450×450 mm )

Polarization Light for PET Preform

1 100% EU Origin

S+S Regeltechnik Vietnam

Model: 1302-4026-0000-000

DS-205 F

Differential pressure sensor

1 100% Germany Origin

Weforma Vietnam

model: SONS21910LKL530

WS-M 0,5 x 13L-KL-530

Shock Absorber

Mega-Line, self-compensating

M 20 x 1,5

1 100% EU/China Origin

Siemens Vietnam

Model: 6GK5224-4GS00-2AC2

SCALANCE XC224-4C G
