List code giá Nidec-Avtron 4/3/2026 Tổng hợp tất cả các sản phẩm hiện đang sẵn khi và giao ngay.
List code Nidec-Avtron 4/3/2026
JonJul là nhà cung cấp tất cả các sản phẩm tự động chính hãng trên toàn thế giới.
Nidec-Avtron Vietnam – Nidec Avtron Vietnam – NidecAvtronvietnam – Nidec-Avtron Viet Nam – Nidec-Avtron-Vietnam
1. Code: AV56A1KFX6YXGP50
Replaces part number AV56A1TFX1YXG007
THIN-LINE™ III Heavy Mill Duty Magnetic Modular Encoder 4.5″” C-Face Mount
Housing Type: 1 – Single Output
Rotor Bore Size: KF – 1 1/8″” Thru-Shaft Cam Screw Rotor for Wolong/GE Pitch Motor
Cover Style : X – No Cover Plate
Line Driver: 6 – 5-24v in, 5-24v out (7272) recommended for single-ended wiring (A,B,Z, no A/,B/,Z/)
Left Output PPR: Y – 1024 PPR
Right Output PPR: X – No Right Output, Single Output Only
Connector Options: G – Ind’l w/Northstar Pinout (EPIC Style connector), w/mating plug, LED diagnostics
Modifications: P50 – Special options for GE Motor, upgraded model including diagnostic LED & cam screw rotor and super magnetic shielding “
2. Code: AV6AS4B23QA2A000
AV6A Solid Shaft Optical Light Mill Duty Absolute Encoder
Communication Bus
S – SSI Communication
Flange
4 – 2.5 in. Square flange, 1.25 in. male pilot
Shaft Size
B – 3/8 inch x 5/8 inch long Solid Shaft, w/flat (flange #4 only)
Turns/bits/MT
2 – 4096 Turns/12 bits
CPR/bits Per Turn/ST
3 – 8192 Counts per Revolution/13 bits
Connector
Q – M23/12 pin w/o Plug, Kubler Pin Out
Connector Exit
A – Side/Radial exit
Output Coding
2 – Gray Coding
IP Rating
A – IP65 Shaft Seals
Modifications
000 – No Special Features “
3. Code: HS35MYX6CPU1CA00
HS35M Hollow Shaft Magnetic Mill Duty Encoder
Left Output PPR: Y – 1024 PPR
Right Output PPR : X – No Right Output
Line Driver: 6 – 5-28v In/Out (7272)
Hollow Shaft Bore Size: C – 5/8 in. via insert
Connector Options: P – 10 Pin Mini-Epic Style with Plug
Mounting: U – Universal (Thru & End of Shaft)
Protection: 1 – Protective Basket Included Anti-Rotational Tether: C – 0.375 16 T-Bolt Fan Cover Tether
Channels and Modifications: A00 – Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\ “
4. Code: HS35MYX6CPU1HA00
HS35M Hollow Shaft Magnetic Mill Duty Encoder
Left Output PPR
Y – 1024 PPR
Right Output PPR
X – No Right Output
Line Driver
6 – 5-24v In/Out (7272)
Hollow Shaft Bore Size
C – 5/8 in. via insert
Connector Options
P – 10 Pin Mini-Epic Style with Plug
Mounting
U – Universal (Thru & End of Shaft)
Protection
1 – Protective Basket Included
Anti-Rotational Tether
H – A and F Tether Kits
Channels and Modifications
A00 – Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\
HS35MYX6CPU1HA00 Replaces part number HS35MYX6HPU1HA00 “
5. Code: HS35MYX6FCU0XA00
HS35M Hollow Shaft Magnetic Mill Duty Encoder Left Output PPR
Y – 1024 PPR
Right Output PPR
X – No Right Output
Line Driver
6 – 5-24v In/Out (7272)
Hollow Shaft Bore Size
F – 1 in. (Native Bore)
Connector Options
C – 10 Pin MS Style with Plug, Avtron/BEI Phasing
Mounting
U – Universal (Thru & End of Shaft)
Protection
0 – No Protective Basket
Anti-Rotational Tether
X – No Tether Hardware
Channels and Modifications
A00 – Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\ “
6. Code: HS35MYX6FCU1HA00
HS35M Hollow Shaft Magnetic Mill Duty Encoder
Left Output PPR
Y – 1024 PPR
Right Output PPR
X – No Right Output
Line Driver
6 – 5-24v In/Out (7272)
Hollow Shaft Bore Size
F – 1 in. (Native Bore)
Connector Options
C – 10 Pin MS Style with Plug, Avtron/BEI Pin Out
Mounting
U – Universal (Thru & End of Shaft)
Protection
1 – Protective Basket Included
Anti-Rotational Tether
H – A and F Tether Kits
Channels and Modifications
A00 – Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\
HS35MYX6FCU1HA00 Replaces part number RA35MY6FCU1HA00 “
7. Code: HS35MYX8FPU1CA00
HS35M Hollow Shaft Magnetic Mill Duty Encoder
Left Output PPR : Y – 1024 PPR
Right Output PPR : X – No Right Output
Line Driver : 8 – 5-24v In/Out (HX)
Hollow Shaft Bore Size : F – 1 in. (Native Bore)
Connector Options : P – 10 Pin Mini-Epic Style with Plug
Mounting: U – Universal (Thru & End of Shaft)
Protection: 1 – Protective Basket Included Anti-Rotational Tether: C – 0.375 16 T-Bolt Fan Cover Tether
Channels and Modifications: A00 – Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\ “
8. Code: M6-4S2HX51-W003
M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1
Hollow Shaft Bore Size : 4 – 1 inch Hollow Shaft
Mounting : S – Standard End-of-Shaft Mounting
Line Driver : 8 – 5-24V In/Out Protected Line Driver
Left Output : H – High Res.
Right Output : X – No Right Output
Base PPR: 51 – 512 PPR
Marker : – – No Marker
Connector Options : W – Terminal with Cable Gland
Modifications: 003 – Includes B28390 Torque Arm Kit “
9. Code: M6C-4S1HX51-W003
M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1
Hollow Shaft Bore Size : 4 – 1 inch Hollow Shaft
Mounting : S – Standard End-of-Shaft Mounting
Line Driver : 8 – 5-24V In/Out Protected Line Driver
Left Output : H – High Res.
Right Output : X – No Right Output
Base PPR: 51 – 512 PPR
Marker : – – No Marker
Connector Options : W – Terminal with Cable Gland
Modifications: 003 – Includes B28390 Torque Arm Kit
M6C-4S1HX51-W003 Replaces the obsolete M6-4S1HX51-W003 “
10. Code: M6C-4S8HX51-W003
DESCRIPTION: M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1
Hollow Shaft Bore Size: 4 – 1 inch Hollow Shaft
Mounting: S – Standard End-of-Shaft Mounting
Line Driver: 8 – 5-24V In/Out Protected Line Driver
Left Output: H – High Res
Right Output: X – No Right Output
Base PPR : 51 – 512 PPR
Marker: – – No Marker
Connector Options: W – Terminal with Cable Gland
Modifications: 003 – Includes B28390 Torque Arm Kit “
M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1
Hollow Shaft Bore Size : 5 – 1-1/8 inch Hollow Shaft
Mounting : S – Standard End-of-Shaft Mounting
Line Driver : 8 – 5-24V In/Out Protected Line Driver
Left Output : X – No Left Output
Right Output : H – High Res.
Base PPR : 51 – 512 PPR
Marker : – – No Marker
Connector Options: T – Terminal Block
Modifications : 003 – Includes B28390 Torque Arm Kit
**Replacement for the obsolete M6-5S3XH51-T003…..Please confirm before ordering…”
12. Code: M6C-5S8XH51-T005
M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1
Hollow Shaft Bore Size : 5 – 1-1/8 inch Hollow Shaft
Mounting : S – Standard End-of-Shaft Mounting
Line Driver : 8 – 5-24V In/Out Protected Line Driver
Left Output : X – No Left Output
Right Output : H – High Res.
Base PPR : 51 – 512 PPR
Marker : – – No Marker
Connector Options: T – Terminal Block
Modifications : 005 – -40C Tested Unit with Torque Arm Kit Included ”
